SANWA Analog Multimeter with Built-In Case YX360TRF

Specifications

• Function: Measuring Range > Tolerance >
• DCV: Measuring Range > 0.1（20kΩ/V), 0.25/2.5/10/50, （20kΩ/V)/250/1000V（9kΩ/V), | Tolerance > ±5% of full scale, ±3% of full scale
• DCV (NULL) : Measuring Range > ±5/25V（40kΩ/V) | Tolerance >             ±5% of full scale
• ACV: Measuring Range > 10/50/250/750（9kΩ/V) | Tolerance > ±4% of full scale
• DCA: Measuring Range > 50μ/2.5m/25m/0.25A  | Tolerance > *1 ±3% of full scale
• Resistance: Measuring Range > 2k/20k/200k/2MΩ (x1/x10/x100/x1k) 200MΩ (x100k) | Tolerance > ±3% of arc, ±5% of arc
• Capacitance: Measuring Range > 10μF | Tolerance > Approximate value
• dB: Measuring Range > -10dB～+22dB (for 10VAC) ～+62dB | Tolerance > Approximate value
• Load current (LI) : Measuring Range > 0-150m/15m/1.5m/150μ/1.5μA | Tolerance > Approximate value
• DC high voltage: Measuring Range > DC25kV (optional probe “HV-10T” is necessary)
• hFE: Measuring Range > 1000 at x10 range (optional probe “HFE-6T” is necessary)
• Battery: Measuring Range > R6 (IEC) or UM-3 (1.5V)x2
• Fuse: Measuring Range > Φ5.2x20mm (250V/0.5A)
• Size/Mass: Measuring Range >  H159.5×W129×D41.5mm/Approx. 320g
• Note: *The value in (　）at DCV and ACV is input resistance, **1 Not including the resistance of fuse.

Features:

• Capacitor: Capacitor capacity (electrostatic capacity) is measured in F (farad), μF, etc.
• Battery Check: Battery voltage is measured and assessed by running a given current.
• Drop Shock Proof: The meter element is constructed with a taut band and impact-resistant design.
• hFE: Provided with graduations for measuring the DC current amplification factor (hFE) of a transistor.
• Zero Center Meter (NULL): Moves the indicator of the analog tester to the center of the scale for measurement of positive and negative voltage.

The YX360TRF is a taut-band type meter designed for low-voltage circuit measurements. It can measure DCV, DCA, AC, resistance, capacitance(10uF), Load line current, Signal power in dB as well as high DC voltage of up to 25kV using an HV-10T probe (optional). When measuring DCV the meter utilizes the Null reading for ±25V with an accuracy of ±5% full-scale accuracy.

This multimeter has a solid cover that provides protection against drop shocks, and conveniently folds over to use as a tilt stand, and features a compartment for storing the attached test leads. For circuit protection, the device features a replaceable fuse rated at (250V / 0.5A).

Meter includes attached test leads and instruction manual.

• Drop shock proof meter
• Null (zero center) meter ±5 / ±25 in DCV
• High resistance up to 200MΩ with low voltage
• Solid & protective body cover that can also be used as a tilt stand
• Capacitance, dB, LI measurement
