USB Humidifier Spray Module 5V Circuit Board Atomization Atomizer DIY kit

Product description

• PCB board size: 35mm*19mm/1.38*0.75inch
• Voltage: 5V
• Current: 300mA
• Frequency: 110KHz
• Power: 2W
• Aperture: 5um
• Holes: 740
• Wire length: 80mm/3.15inch
• Atomized steel sheet diameter: 16mm/0.63inch
• Rubber ring diameter: 20mm/0.79inch
• Rubber ring thickness: 4mm/0.16inch
• Atomizer material: shockproof silicone ring, piezoelectric ceramic ring, stainless steel sheet

Features:
Pay attention to the front and back sides during installation. The white piezoelectric ceramic ring surface is the front spray surface, which is installed upward. All steel sheet surface is the suction surface on the back, installed downwards

• High-frequency oscillation, micrometer aperture, large atomization amount, fine mist particles, high spray rate
• The atomizing piece needs to be used together with the circuit board with the same frequency to achieve the ideal spray amount
• The left and right welding points of the switch can be welded together to realize power on, i.e. spray, without the need to control the switch
• There are two wires, the red wire is positive and the black wire is negative. The wire is 80mm long and there are terminal blocks at the end of the wire
• There is waterproof adhesive on the welding points of the wires to prevent circuit breakers, and a silver oxide layer on the surface of the atomizing sheet to protect the coating from oxidation
