N20 Gear Motor 3x7mm D-Shaft 20mm Motor Body High Torque Micro DC Geared Motor

Specifications

• N20 Geared Motor DC
• Motor Body Dimensions: 12mm x 10mm cross-section, 20mm length
• Overall Length (approx.): 36mm (including gearbox and shaft)
• Shaft Type: D-shaped
• Shaft Diameter: 3mm
• Shaft Flat-to-Flat: 7mm
• Shaft Length: 7mm (protruding)
• Gearbox Material: Metal (brass and steel gears)
• Motor Material: Metal casing
• Operating Voltage: 3V – 12V DC (commonly 6V or 12V)
• No-Load Speed: Varies by ratio (e.g., 30-500 RPM at rated voltage)
• Torque: High torque depending on gear ratio (up to several kg.cm stall)
• Current: Low no-load current (~20-70mA), stall current varies
• Weight: Approx. 10-12g
• Application Temperature: -10°C to +60°C

Features

• Compact N20 series micro DC geared motor with metal gearbox for durability
• D-shaped shaft (3mm diameter, 7mm flat-to-flat) for secure grip and easy mounting
• 20mm motor body length for space-constrained applications
• High torque output suitable for robotics, models, smart locks, and DIY projects
• Low noise operation and long lifespan
• Reversible direction (CW/CCW)
• Available in multiple RPM ratios and voltages (3V-12V)
• Easy to solder with pin terminals
• The N20 Gear Motor with 3x7mm D-Shaft and 20mm motor body is a premium micro DC geared motor designed for precision applications requiring high torque in a tiny package. Featuring a robust metal gearbox and a D-cut shaft (3mm round diameter with 7mm flat measurement for anti-slip fitting), this motor ensures secure attachment of gears, wheels, or couplings without slipping.
• The compact 20mm motor length (body excluding extended gearbox) makes it ideal for tight spaces in robotics projects, RC models, smart door locks, automated toys, camera gimbals, and small mechanisms. The metal construction provides excellent durability, low noise, and resistance to wear compared to plastic gearbox variants.
• Operating on 3V to 12V DC, it offers a wide range of speed and torque options depending on the gear ratio – from slow high-torque for precise movements to faster speeds for quick actions. With reversible polarity for bidirectional rotation, it’s perfect for Arduino, Raspberry Pi, or any microcontroller-based DIY electronics. Reliable performance, easy integration, and availability in Bangladesh make this N20 variant a top choice for hobbyists and engineers.

What is the price of N20 Gear Motor 3x7mm D-Shaft 20mm Motor Body High Torque Micro DC Geared Motor in Bangladesh?

The latest price of N20 Gear Motor 3x7mm in Bangladesh starts from Price: ৳200.00 taka for 1Pcs Tweezer. You can buy this product at a better and cheaper price from our website and also you can visit our warehouse between work hours 10am to 8pm.

Buy N20 Gear Motor 3x7mm D-Shaft 20mm Motor Body High Torque Micro DC Geared Motor in Bangladesh from online at Dunia.com.bd.

In Bangladesh, you can get original N20 Gear Motor 3x7mm From Dunia.com.bd. We have few collection of latest DC Motor to purchase. Order Electric Motor Online at our website Or Visit our warehouse to get your product at lowest price.

FAQ

1. What is the shaft size of this N20 gear motor?
   The shaft is D-shaped with 3mm diameter and 7mm flat-to-flat measurement, protruding about 7mm.
2. What is the motor body length?
   The motor body is 20mm long, making it more compact than standard N20 models.
3. What voltage does this N20 motor support?
   It operates on 3V to 12V DC, with common ratings at 6V or 12V for optimal performance.
4. Is the gearbox made of metal?
   Yes, it features a full metal gearbox (brass and steel) for higher durability and torque handling.
5. Can this motor be used for robotics projects?
   Absolutely, it’s widely used in small robots, wheeled bots, arms, and mechanisms due to its high torque and compact size.
6. Does it support bidirectional rotation?
   Yes, simply reverse the polarity to change direction (CW/CCW).
7. What is the typical speed range?
   Speed varies by gear ratio; common options include 30RPM to 500RPM at rated voltage (custom ratios available).
8. Is this motor suitable for high-torque applications?
   Yes, the metal gears provide strong stall torque, ideal for loads requiring significant force in small setups.
9. How to mount accessories on the shaft?
   The D-shaped design ensures secure fit for wheels, gears, or couplers without needing extra set screws.
10. Where can I buy this N20 motor in Bangladesh?
    Available at Dunia BD with fast delivery in Dhaka and nationwide – check for various RPM options.
