20 Ohm 200 1206 SMD Resistor 1/4W 1% Tolerance Precision Chip Resistor

Specifications

• 20 Ohm 200 1206 SMD Resistor 1/4W
• Resistance Value: 20 Ohm (200 marking)
• Tolerance: ±1%
• Power Rating: 1/4W (0.25W)
• Package/Case: 1206 (3216 Metric)
• Technology: Thick Film
• Temperature Coefficient: ±100 ppm/°C (typical)
• Operating Temperature Range: -55°C to +155°C
• Maximum Working Voltage: 200V (typical)
• Dimensions: 3.2mm × 1.6mm × 0.55mm (approximate)
• Mounting Type: Surface Mount (SMD/SMT)
• Termination: Wraparound / Solderable

Features

• High ±1% tolerance for accurate and repeatable resistance
• Compact 1206 case (3.2 × 1.6 mm) perfect for space-constrained boards
• 0.25W power rating suitable for low to medium power applications
• Thick film technology provides excellent reliability and surge handling
• Wide operating temperature: -55°C to +155°C typical
• RoHS compliant, lead-free, halogen-free
• Strong solderability for automated and manual assembly
• Low temperature coefficient ensures minimal resistance drift
• The 20 Ohm (marked 200) 1206 SMD Resistor with ±1% tolerance and 1/4W power rating is a dependable precision component engineered for demanding electronic applications. Built with thick film resistive material on a high-quality ceramic substrate, it offers superior long-term stability, low noise, and consistent performance across a broad temperature range.
• The industry-standard 1206 footprint is widely used in automated production, densely populated PCBs, consumer electronics, power supplies, LED current limiting, battery management systems, sensors, IoT devices, and professional repair work. Its tight 1% tolerance makes it especially suitable for circuits requiring accurate current limiting, voltage references, timing networks, or balanced signal paths.
• Rated for 200V working voltage and 0.25W dissipation, it handles typical operating conditions reliably. Fully RoHS compliant and optimized for reflow, wave, and hand soldering processes.
• Ideal for bulk manufacturing, hobby electronics, service centers, and educational projects—this 20Ω 1206 1% resistor combines precision, durability, and affordability. Available in full reels, cut strips, or sample quantities.

What is the price of 20 Ohm 200 1206 SMD Resistor 1/4W ±1% Tolerance in Bangladesh?

The latest price of 20 Ohm 200 1206 SMD Resistor 1/4W in Bangladesh starts from Price: ৳21.00 taka for 10 Pcs Resistor. You can buy this product at a better and cheaper price from our website and also you can visit our warehouse between work hours 10am to 8pm.

Buy 20 Ohm 200 1206 SMD Resistor 1/4W ±1% Tolerance in Bangladesh from online at Dunia.com.bd.

In Bangladesh, you can get original 20 Ohm 200 1206 SMD Resistor 1/4W From Dunia.com.bd. We have few collection of latest Resistor to purchase. Order Electronics Component Online at our website Or Visit our warehouse to get your product at lowest price.

FAQ

1. What does the “200” code mean on this 1206 resistor?
   “200” is the standard 3-digit SMD code for 20 Ohms (20 × 10⁰ = 20Ω).
2. Can I use this resistor above 0.25W power?
   No — exceeding 1/4W (0.25W) continuously may cause excessive heat and failure.
3. Why is 1% tolerance better than 5% for some circuits?
   1% tolerance keeps resistance within ±0.2Ω of 20Ω, critical for precision analog and feedback circuits.
4. Is 1206 size easy to solder by hand?
   Yes, 1206 is beginner-friendly for hand soldering compared to smaller packages like 0402 or 0603.
5. What are the physical dimensions of a 1206 resistor?
   Approximately 3.2 mm length × 1.6 mm width × 0.55 mm height.
6. Is this resistor RoHS and lead-free?
   Yes, modern 1206 SMD resistors are typically RoHS compliant and lead-free.
7. What temperature does it operate in safely?
   Standard range is -55°C to +155°C for reliable performance.
8. Can it be used in automotive or industrial environments?
   Yes, provided voltage, power, and temperature remain within rated limits.
9. How is 20Ω usually marked on SMD resistors?
   Most manufacturers use the 3-digit code “200” for 20 Ohms.
10. Are these resistors available in reels for machine placement?
    Yes, standard packaging is 5,000 pieces per reel for pick-and-place machines.
