TB Series Terminal Block are Panel Mounted Terminal Block , the basic color is black. The product color can be changed according to the customer requirements. There are reserved install holes on both sides. Load current can be 15A, 25A, 35A. The products are with a Protective Cover, whose materials are PS, this makes the products are durable. Marker Strip is not required, it is mold printed.
|
Rated Volt [V] | 600V |
Rated Current [A] | 25A |
Wire Size [mm2] | 6.0 mm2 |
Wire Size [AWG] | AWG 10 |
Insulator Materials | PC |
Color | Black (White, Blue, Red, Brown) |
Flame Retarded Grade | UL94V-2 (UL94V-0) |
Operating Temperature [℃] | -40℃+110℃ (Max: +220℃) |
Conductor | Brass, Nickel Plated (Copper, Tin Plated) |
Poles | 6, 12 |
Weight | 50g |
