IRF3205 TO-220AB N-Channel MOSFET Transistor

Port Description:

1. Gate G controls the bias of the MOS transistor
2. The drain D current flows through the drain
3. The source S current flows out through the source

IRF3205 FET parameters:

• The drain-source breakdown voltage (V BR (DSS)) is 55V
• The gate-to-source voltage (Vgs) is +/- 20V
• The threshold voltage (Vg (th)) of the gate is 2 to 4 V
• The drain current (Id) is 110A
• The pulsed drain current (IMD) is 390A
• The power consumption is (PD) of 200W
• Drain-to-source on-resistance ( R DS (ON) ) 8mΩ
• The leakage current (ISSS) of the door body is 100nA
• The total gate charge (Qg) is 146nC
• The reverse recovery time (TRR) is 69 to 104ns
• Peak diode recovery (dv/dt) is 5V/ns
• The rise time (TR) is 101ns
• The crust thermal resistance (R th jc) is 75°C/W
• The junction temperature (Tj) is between -55 and 175°C

Product Description:

• The power MOSFET IRF3205 is manufactured using advanced process technology and has a very low on-resistance
• IRF3205 is a high-current N-channel MOSFET capable of switching currents up to 110A and voltages up to 55V
• The specialty of MOSFETs is that they have a very low on-resistance of only 8.0mΩ, making them suitable for switching circuits such as inverters, motor speed control, DC-DC converters, etc
• It is important to note that IRF3205 has a high threshold voltage and is therefore not suitable for on/off control of embedded controllers
• Available in a TO-220AB package

What is the price of IRF3205 TO-220AB N-Channel MOSFET Transistor in Bangladesh?

The latest price of IRF3205 TO-220AB Power MOSFET Transistor N-Channel in Bangladesh is Price: ৳79.00 Original price was: ৳79.00.৳67.00Current price is: ৳67.00. taka for 1or 2Pcs Transistor. You can buy this product at better and cheaper price from our website and also you can visit our warehouse between work hours 10am to 8pm.

Buy IRF3205 TO-220AB N-Channel MOSFET Transistor in Bangladesh from online at Dunia.com.bd.

In Bangladesh, you can get original IRF3205 TO-220AB Power MOSFET Transistor N-Channel From Dunia.com.bd . We have few collection of latest Uncategorized to purchase. Order Online at our website Or Visit our warehouse to get your product at lowest price.
