DC-005 Power Jack Black Socket PCB Mount Connector with 3Pin

Specifications

• Model: DC-005B
• Type: Female DC Power Jack / Socket
• Mounting Style: SMT (Surface Mount)
• Number of Pins: 3 pins
• Rated Voltage: 50V DC (some sources mention 30V DC in alternate spec)
• Rated Current: 0.2A DC
• Contact Resistance: ≤ 0.03 Ω
• Insulation Resistance: ≥ 100 MΩ (at 250 V DC, 1 min)
• Withstand Voltage: AC 500V, 50 Hz, 1 min
• Insertion/Withdrawal Force: 3 – 20 N
• Mechanical Life: ~5,000 cycles
• Operating Temperature: –40 °C to +55 °C (typical)
• Insulating Material: Plastic / Nylon / PBT (commonly used)
• Contact Material: Copper alloy (plated)
• Compatible Plug Sizes: 5.5 mm × 2.1 mm or 5.5 mm × 2.5 mm (depending on design)

Why Choose the DC-005B?

• Compact SMT footprint for modern board layouts

• Reliable 3-pin design for stable connections

• Good electrical performance with low resistance and high insulation

• Durable mechanical life for repeated usage

• Well suited for low-current, low-voltage electronics


Applications:

• Consumer electronics (DVD players, radios, portable devices)

• Security systems, surveillance modules, IoT devices

• Audio and video equipment

• DIY electronics / hobbyist PCB projects

• Embedded control modules and compact power circuits

Features:

• Elevate your electronics design with the DC-005B 3-Pin SMT DC Power Jack (Female Socket) — a reliable, space-efficient solution for power input in compact devices and PCBs.
• This connector is engineered for durability and consistency. With a 3-pin configuration, it offers a secure ground, signal, and power line interface. The SMT (surface mount) design enables easy automated PCB assembly and helps save board space.
• Rated for up to 50 V DC / 0.2 A, this jack is ideal for low-power electronics, sensors, small appliances, audio/video modules, and embedded systems. It features a contact resistance as low as 0.03 Ω, ensuring minimal voltage drop and efficient current flow. The insulation resistance exceeds 100 MΩ at 250 V DC, providing excellent isolation against leakage currents.
• Safety and robustness are integral: the connector can endure AC 500 V withstand voltage for 1 minute, and mechanical durability reaches up to 5,000 insertion/removal cycles. It operates reliably across a wide temperature range (approximately –40 °C to +55 °C), making it suitable for varied environmental conditions.
• Fabricated using high-quality plastic materials (such as nylon or PBT) and plated copper alloy contacts, the DC-005B ensures long-term stability and corrosion resistance.
