KCD4-203 DPDT 16A 250v AC Non-Illuminated 6Pin 3Position ON-OFF-ON Switch

KCD4-203 DPDT 16A 250v AC 6Pin 3Position ON-OFF-ON Switch

Name: KCD4-203 DPDT 16A 250v AC 6Pin 3Position ON-OFF-ON Switch - Dunia.com.BD
SKU: 201189
Price: 50.00 BDT
Availability: InStock
Rating: 5.00 (3 reviews)

Rated 5 out of 5 based on 3 customer ratings

(3 customer reviews)

৳50.00

10 in stock

SKU: 201189 Category: Rocker Switch Tag: DPDT Switch

Description

This Rocker switch KDC4-203
Contact Type: DPDT
Terminals: 6 Pins (3 Position ON/Off/ON)
Rated Voltage & Current: AC 20A/125V 16A/250V( This switch can use 12V )
Mechanical life: more than 80.000 cycles
Electrical life: more than 10, 000 cycles
Mounting Size: 26 x 21.5mm / 1.02″ x 0.85″ (L*W)
Overall Size: 30 x 25 x 31mm / 1.18″ x 0.98″ x 1.22″ (L*W*H)
Package content: 1 X Rocker switch
Contact resistance : 50mΩ max
Insulation resistance : 100MΩ min at 500Vdc

What is the price of KCD4-203 DPDT 16A 250v AC 6Pin 3Position ON-OFF-ON Switch in Bangladesh?

The latest price of KCD4-203 DPDT 16A 250v AC 6Pin 3Position ON-OFF-ON Switch in Bangladesh is Price: ৳50.00 taka for 1Pcs Switch. You can buy this product at better and cheaper price from our website and also you can visit our warehouse between work hours 10am to 8pm.

Buy KCD4-203 DPDT 16A 250v AC 6Pin 3Position ON-OFF-ON Switch in Bangladesh from online at Dunia.com.bd.

In Bangladesh, you can get original KCD4-203 DPDT 16A 250v AC 6Pin 3Position ON-OFF-ON Switch From Dunia.com.bd . We have few collection of latest Rocker Switch to purchase. Order Switch Online at our website Or Visit our warehouse to get your product at lowest price.

Additional information

Weight	11-14 g
Dimensions	15 × 10 × 5 cm

Reviews (3)

3 reviews for KCD4-203 DPDT 16A 250v AC 6Pin 3Position ON-OFF-ON Switch

+2
Shahariar
Rated 5 out of 5
06/06/2026
Awesome quality switch, very big in size, smooth clicky snappy switching between On-Off-On. Excellent choice for AC/DC application with 2 load switchi...More
Awesome quality switch, very big in size, smooth clicky snappy switching between On-Off-On. Excellent choice for AC/DC application with 2 load switching, changeover circuit design, break before make style source switching, DC motor direction control without IC. This is a 3 position switch with essentially 2 switches inside one switch which is called DPDT or Double Pole Double Through switch.
